OneSport OT05 City E-Bike(Specs)
| Feature | Specification |
|---|---|
| Frame | 27.5" Aluminum Frame |
| Color Options | Blue, White, Blue-grey |
| Maximum Load | 100 KG |
| Maximum Speed | 25 KM/H |
| Range | 60 KM in Pure Electric Mode, 120 KM in Pedal Assist Mode |
| Maximum Climbing Angle | 20 Degree |
| Instrument Display | 3-speed Multi-function LCD with Bluetooth |
| Front Lighting | Included |
| Braking Method | Integrated Oil Disc Power Off Brake Handle |
| Hub Form | Spoked Wheel |
| Tire Specifications | Pneumatic Tires |
| Front Fork | Iron Shock Absorber Front Fork (Non-adjustable) |
| Gear | Shimano 7 Speed |
| Riding Mode | Pedal Assist Mode (Torque Sensing), Riding Mode, Pure Electric Mode |
| Fenders | Front and Rear Fenders |
| Seat Tube | Aluminum Alloy |
| Battery | 36V 18.2AH 18650 Battery Cell |
| Motor | 36V 250W |
| Motor Brand | ANANDA |
| Motor Torque | 40 Nm |
| Charger | 42V 2A (Input: 110V-240V) |
| Charging Time | 8-10 Hours |
| Controller | Sine Wave Controller (48V 15A Jing Hui Controller) |
OneSport OT05 City E-Bike(Size)
| Feature | Specification |
|---|---|
| Length | 1850 MM |
| Rear Height | 680 MM |
| Front Height | 1080 MM |
| Handlebar Length | 680 MM |
| Packing Size | 1480 MM x 240 MM x 790 MM |
| Tire Size | 27.5" x 2.25 Inches |
| Net Weight/Gross Weight | 28 KG / 35.5 KG |
| Battery Size | 433 MM x 98 MM x 93 MM |
| Battery Net Weight | 4 KG |
| Saddle Height | 860 MM - 1050 MM from the Ground |
| Disc Diameter | 180 MM |
| Front Fork Travel | 80 MM |
| Applicable Height | 1600 MM - 2000 MM |
