OneSport OT18-3 E-Bike(Specs)
| Feature | Specification |
|---|---|
| Body Material | Steel |
| Frame | 20" Folding Iron Frame |
| Color Options | Black, White; Black-Red, Off-White, Black-Brown |
| Maximum Load | 120 KG |
| Maximum Speed | 25 KM/H |
| Range | 40 KM in Pure Electric Mode; 60 KM in Pure Electric Mode, 120 KM in Pedal Assist Mode |
| Maximum Climbing Angle | 25 Degree; 20 Degree |
| Instrument Display | 3-speed Multi-function LCD with Bluetooth |
| Front Lighting | Included |
| Tail Light | Included |
| Braking Method | Front Disc Brake + Rear Disc Brake |
| Hub Form | Wire Spoke Wheel; Integrated Wheel |
| Tire Specifications | Pneumatic Tires |
| Front Fork | Suspension Fork; Iron Shock Absorber Front Fork (Non-adjustable) |
| Gear | Shimano 7-speed |
| Riding Mode | Pedal Assist Mode, Riding Mode, Pure Electric Mode |
| Front Fender | Included |
| Rear Fender | Included |
| Seat Tube | Aluminum Alloy |
| Throttle | Half Throttle (Not Installed and Packed) |
| Foldable | Yes |
| Length | 1640 MM |
| Rear Height | 560 MM |
| Front Height | 1190 MM |
| Handlebar Length | 560 MM |
| Packing Size | 910 MM x 380 MM x 745 MM |
| Net Weight/Gross Weight | 29.7 KG / 36.5 KG |
| Battery Size | 380 MM x 110 MM x 78 MM |
| Battery Net Weight | 4 KG |
| Saddle Height | 890 MM - 1000 MM from the Ground |
| Disc Diameter | 160 MM |
| Front Fork Travel | 40 MM |
| Applicable Height | 1600 MM - 2000 MM |
| Battery Type | 18650 Lithium Ion Power Battery |
| Battery Capacity | 14.4Ah |
| Battery Rated Voltage | 36V |
| Motor Form | Assist Mode |
| Motor Type | 20 Inches / High-speed Gear / Spoke Wheel Brush-less Motor |
| Motor Rated Power | 250W |
| Motor Rated No-Load Speed | 300 ± 10 r/Min |
| Motor Brand | ANANDA |
| Motor Torque | 40 Nm |
| Controller | 6-MOSFET Controller; Sine Wave Controller (48V 15A Jing Hui Controller) |
| Charger Output | 42V 2.0A |
| Charger Input | 100~240V 50/60Hz 3.0A |
| Under Voltage Protection Value | 29V ± 1V |
| Over Current Protection Value | 15A ± 1A |
| Charging Time | 6.5~7 Hours; 8-10 Hours |
OneSport OT18-3 E-Bike(Size)
| Feature | Specification |
|---|---|
| Length | 1780 MM |
| Rear Height | 730 MM |
| Front Height | 1060 MM |
| Packing Size | 1480 MM x 220 MM x 765 MM |
| Tire Size | 26 x 2.35 Inches |
| Net Weight/Gross Weight | 27.5 KG / 34 KG |
| Battery Size | 390 MM x 75 MM x 105 MM |
| Front Handle Adjustable Height | 1060 MM - 1160 MM |
| Saddle Height | 850 MM - 1100 MM |
| Brake Pad Diameter | 160 MM |
